Kns antenna marine Supertrack S6 tvro system 61cm dish
Kns antenna marine S6 – Ku
The art KNS 3 axis servo stabilization system and the built-in GPS, The S-Series outperforms all other TVRO systems in the market today.
Larger S-Series antennas providing stronger signal acquisitions are available for more efficient performance in any condition.
Standard Features
- Automatic Satellite Search & Skew Control
- Accurate Signal Acquisition by KNS’s Distinctive Algorithm
- Pre-programmed Satellite Database
- Editable 80 satellite data
- Antenna Control Unit
- DiSEqC 1.2 function
- CE (EN60945) Satisfied
- True 3 Axis
- DiSEqC 1.2 function
- Antenna Control Unit
- Editable 80 satellite data
| Dish Diameter | 61cm(24”) |
|---|---|
| Antenna Dimension | 85cm(D) x 84cm(H) |
| Antenna Weight | 38 Kg |
| Radome Material | Honeycomb FRP |
| Frequency | 10.75 ~ 12.75 GHz |
| Minimum EIRP | 46 dBW |
| Operating Platform | 3 – Axis |
| LNB | Quad / Quattro LNB(optional) |
| Skew Control | Automatic |
| Elevation Angle | -10˚ to +95˚ |
| Azimuth Range | 640˚ |
| Cross Angle | ± 35˚ |
| Ship Motion | Roll : ±20˚ at 8-12 sec periods Pitch : ±10˚ at 6-12 sec periods Yaw : ±8˚ at 15-20 sec periods |
| Tracking Speed | More than 90˚/sec |
| Vibration Damper | Rubber Damper included |
| Temperature | -20˚C to +55˚C |
| Humidity | Up to 100% @ 40˚C |
| Antenna Input Power | 24V DC, 4.17A |
| ACU Size | 253 x 175 x 44 cm |
|---|---|
| Gyro Interface | NMEA 0183 |
| Input Power | 100 – 240V AC, 50/60Hz, 2.8A |
| Output Power | 24V DC, 4.17A |
| External I/O | Mini-USB |
| Size | 95 x 95 x 115 cm |
|---|---|
| Gross Weight | 65kg |
| Packed by | Paper Carton |
WARRANTY INFORMATION
KNS offers 2-year parts, 1-year onboard labour warranty for the SuperTrack S-Series
1
WARRANTY
We are serious about our professional services and business. We strive to provide the highest level of support and products. KNS Inc will support its SuperTrack S-Series products with an exclusive TWO (2) YEAR, 100% Warranty on PARTS from KNS, and a ONE (1) YEAR Warranty on LABOR from Authorized Dealer (Seller).
